1. Easy to operate
2. The most reasonable layout
3. Closed centralized ink supply system1. Easy to operate
The central computer program concentrates on the man-machine interface operation. A general worker can operate the entire machine proficiently after a week of operation practice, and the operation interface is easy to understand and does not require a high degree of education.
2. The most reasonable layout
The most popular layout at the moment, the design is reasonable and easy to operate: the layout of the whole machine refers to the best feeding method in Europe, the film path is short, and the operation is convenient.
3. Closed centralized ink supply system:
The fully enclosed ink circuit design completely eliminates the pollution of ink splashes to the printing environment and air, and improves the quality of printed products.
|
Printing colors: |
6 colors on one side |
|
Maximum width of substrate: |
1250mm |
|
Maximum printing width: |
1200mm |
|
Printing repeat length: |
360-980mm |
|
Printing specification change: |
10mm(The corresponding printing length of 1 tooth changes 10MM) |
|
Maximum rewinding and unwinding diameter: |
Φ600mm |
|
Maximum mechanical speed: |
250m/min |
|
Printing speed: |
30-250m/min(depending on the characteristics of substrate,printing plate and ink) |
|
Main transmission mode: |
high-precision gear transmission |
|
Registration System: |
CNC online registration system Horizontal:±10mm Longitudinal:±7.5mm |
|
Overprint accuracy： |
±0.1mm |
|
Tension control: |
Four-stage closed-loop tension automatic control,using ultra-light floating roller and sensor control system |
|
Tension control accuracy: |
±0.5KG |
|
Print length control accuracy: |
±2mm |
|
Plate thickness: |
Photosensitive resin plate 1.7mm |
|
Mounting tape: |
0.38mm thickness0.38mm |
|
Version roll printing length: |
selected by the customer |
|
Ceramic anilox roller: |
selected by the customer |
|
Uitable for printing materials: |
Breathable film,non-woven fabric,PE,OPP,PET,PVC |
|
Suitable for printing ink: |
water-based environmentally friendly ink,solvent ink |
|
Loading method: |
3 inch air shaft loading |
|
Total power of the whole machine: |
120KW |
|
Drying method: |
electric heating |
|
Machine weight: |
20T |
|
Overall dimensions: |
13(length)x5(width)x4.5(height)meters 5 meters after opening the oven |
|
Power supply: |
380V±10%50 Hz three-phase five-wire system |
|
Purified dry compressed air source: |
6-8kg/c㎡，1.5m3/min |
|
Water source: |
Pressure greater than 2kg/c㎡ |
